The portable composite gas analyzer can be used in: accurate detection and analysis of a variety of gas concentration and measurement of environmental temperature and humidity. adopted 3.5-inch high-definition color screen for real-time display, adopted the gas sensors of internationally well-known brands, and the main detection principles include: electrochemical, infrared, catalytic combustion, thermal conductivity, PID photoionization, and so on. Adopted Swiss high-precision capacitive digital temperature and humidity sensors. Advanced electric circuit design, mature kernel algorithm processing, unique external appearance design, had achieved a number of patents about the software works, external appearance, and so on. is suitable for detecting the concentrations of gases in the atmosphere environment in the pipeline or confined space; and the purity of the gas leakage and various high concentration single gases with the background gas as nitrogen gas or oxygen gas. The types for detection are more than 500 types.
Model Click to consult
|
Rich human-machine interface |
Infrared remote control |
|
It is possible to switch among three display modes |
Chinese and English interfaces can be selected |
|
It is possible to simultaneously detect 1 ~ 6 types of gases, which can be expanded to 18 or more types of gases, and the units can be switched freely |
|
|
Built-in pump-suction type measurement, built-in water vapor and dust filter, fast response, and the long-distance sampling is supported |
|
|
Function of large-capacity data storage (capacity can be customized), multiple storage modes are supported, and remote wireless transmission function is optional configuration |
|
|
Various kinds of communication interfaces and printing functions |
|
|
Mis-operation recognition function: automatic recognition and prevention of the concentration calibration mis-operation, which is possible to avoid the poor performance that may be caused by human factors |
|
|
Graphical display, and use the form of curve to reflect the trend of gas concentration changes in a certain period of time |
|
|
It is possible to set whether to display the maximum value, minimum value, average value or not |
|
|
Standard USB charging port, with charging protection function, USB hot-plug supported, and the charging status instrument can work properly |
|
|
10000mA high capacity rechargeable polymer battery is adopted, so it is possible to work for a long period of time |
|
|
Real-time detection or timing detection is supported; when no detection will be done, it is possible to shut down the pump so as to extend the startup time |
|
|
Multiple alarm modes, and multi-directional and three-dimensional indication alarm states |
|
|
Multiple alarm mode settings: low alarm, high alarm, interval alarm, and weighted average alarm. |
|
|
Zero-point automatic tracking; long-term use will not be affected by the zero drift |
|
|
Multi-level calibration for target points, can ensure the linearity and accuracy of the measurements |
|
